Description
Dimensions
130mm(L)*167mm(W)*132mm(H)
Printing Features
Print Method:
Direct thermal
Max. Resolution:
203DPI
Interface:
USB+Ethernet(Optional:USB+WiFi / USB+Bluetooth)
Column Number:
80mm paper:
Font A – 42 columns or 48 columns
Font B – 56 columns or 64 columns/
Simplified/Traditional Chinese – 21 columns or 24 columns
Paper Width:
80MM x 82MM(width x diameter)
Print width:
72MM
Line Spacing:
3.75mm
Character Set:
ANK, Font A：1.5×3.0mm(12×24 dots)
Font B：1.1×2.1mm(9×17 dots)
Simplified/Traditional Chinese:3.0×3.0mm(24×24 dots）
Character Enlargement/Rotation:
Both horizontal and vertical directions can be magnified 1-8 times, rotated and inverted
Extension Character Sheet:
P0 437/P1 Katakana/P2 850/P3 860/P4 863/P5 865/P6 WestEurope/P7 Greek/P8 Hebrew/P9 EastEurope/P10 lran/
P16 1252/P17 866/P18 852/P19 858/P20 lranll/P21 Latvian/P22 Arabic/P23 1251/P24 747/P25 WPC1257/
P27 Vietnam/P28864/P29/PC1001/P30 Uyghur/P31 Hevrew/P32WPC1255/P33 PC720/P34 WPC1256/P35 WPC1257(N)/
P36Armenian/P37 PC857(Turkish)/P38 WPC1254(Turkish)/P39Viscli/P40 Georgia/P255 Thai/PP50 PC437/
P51 Katakana/P52 PC437/P53 PC858/P54 PC852/P55 PC860/P56 PC861/P57PC863/P58 PC865/P59 PC866/P60 PC855/
P61 PC857/P62 PC862/P63 PC864/P64 PC737/P65 PC851/P66PC869/P67 PC928/P68 PC772/P69 PC774/P70 PC874/
P71 WPC1252/P72 WPC1250/P73 WPC1251/P74 PC3840/P75 PC3841/P76 PC3843/P77 PC3844/P78 PC3845/
P79 PC3846/P80 PC3847/P81 PC3848/P82 PC1001/P83 PC2001/P84 PC3001/P85 PC3002/P86 PC3011/P87 PC3012/
P88 PC3021/P89 PC3041
Barcode Character
1D Barcode:
UPC-A
UPC-E
JAN13(EAN13)
JAN8(EAN8)
ITF/CODABAR
CODE39
CODE93
CODE128
2D Barcode:
QRCODE
Input Buffer:
30 Kbytes
NV Flash:
60KB
Power
Power Adaptor:
AC 100~240V, 50～60Hz
Printer Input:
DC 24V 1.25A
Cash Drawer Output:
DC 24V 0.5A
Physical characteristics
Weight:
0.84KG
Dimensions:
130.2×167×131.5mm
Auto Cutter:
Partial
Cutter Life:
1.5 million cuts
Printer Head Life:
150KM
Software
Emulation:
ESC/POS
Driver:
PR Driver
SDK:
iOS, Windows、Android
Environmental Requirements
Work Environment:
Temperature (5～40℃) humidity(20～90%)
Storage Environment:
Temperature(-25～55℃) humidity(20～93%)
